Available as a canned motor/pump as well. Viscosity - Type B and I: 33 to 3000 SSU (2.0 to 650CST). Inlet Pressure - 25 PSIG (5 BAR) maximum for types B, H and I. 350 PSIG (24.1 BAR) maximum type N providing differential pressure does not exceed 150 PSI (10.3 BAR). Outlet Pressure - 150 PSIG (10.3 BAR) maximum for types B, H and I. For applications requiring higher inlet and discharge pressures.Īccessories - Completely mounted, built to order pump/driver assemblies are available with baseplates, ANSI RF spool pieces, NEMA ‘C’ face adapters.
Type N, cast iron cased, flange mount, sizes 118 through 200 only: Positive drive, balanced mechanical seal, neoprene o-rings, carbon on carbide sealing faces and external, permanently grease packed, deep groove ball bearing. For applications where pump shaft is within driving machinery enclosure allowing internal return to sump of shaft leakage. Type I: Integral flange mounted pump with sleeve bearing in lieu of a ball bearing and no shaft seal. Type H, sizes 118 through 200: Positive drive mechanical seal, fluoroelastomer o-rings and external high temperature, permanently grease packed, deep groove ball bearing- recommended for residual oils and all applications above 3000 SSU (650 CST). Type B, sizes 118 through 200: Buna N bellows friction drive mechanical seal, Buna N o-rings and standard external, permanently grease packed, deep groove ball bearing- recommended for distillate fuels and lubricating oil or hydraulic fluids. Seal & Bearing - Type B, sizes 87 through 95: Positive drive mechanical seal, Buna N o-rings and standard external, permanently grease packed, deep groove ball bearing for services up to 180☏ (82☌) and/or 25,000 SSU (5400 CST). Gaskets - Cellulose and non-asbestos fiber.
#IMO PUMP PLUS#
Replaceable in all steel case models plus all versions of the 187/200 case size. Three screw pumps are capable of water injection services (Tritec) as well as high-pressure coolant service for machine tools (Emtec).Ĭasing - Pearlitic gray iron. The magnetic drive screw pump is used extensively for pumping isocyanate, a plastic component that is an extremely difficult fluid to seal using conventional technology.Pumps are also now available in sealless canned configurations.Three screw pumps are renowned for their low noise levels, high reliability and long life. They are common in engine rooms on most of the world's commercial marine vessels and many combat ships.Flow rates are available from 1 to 3300 GPM (4 to 13,250 L/M) or for operating pressures to 4500 PSIG (310 BAR).Subject to material selection limitations, three screw pumps are also used for polymer pumping in the manufacture of synthetic fibres such as nylon and lycra.Designs are now available in sealless configurations such as magnetic drives and canned arrangements. Three-screw pumps are the largest class of multiple screw pumps in service today.They are commonly used formachinery lubricationhydraulic elevatorsfuel oil transport and burner servicepowering hydraulic machineryThey are also used in refinery processes for high-temperature viscous products such as asphalt, vacuum tower bottoms and residual fuel oils.Three screw pumps also find extensive use in crude oil pipeline service as well as gathering, boosting and loading of barges and ships.
